Range: 1.50 MFD To 3.15 MFD 50Hz. 440 Volt
Plastic Body-Dry-Pin/Wire Terminals
Range: 2.50 MFD or 4.0 MFD 50Hz. 440 Volt
Pin/Wire-Premium Series
Range: 2.50 MFD To 4.0 MFD 50Hz. 440 Volt
Plastic Body-Dry Epoxy Top
Range: 2.00 MFD To 4.00 MFD 50Hz. 440 Volt
Pin/Wire Terminals
Range: 1.50 MFD To 4.0 MFD 50Hz. 440 Volt
Square Box Type-Epoxy Top Pin/Wire
Download our complete brochure
We are a world class manufacturer and exporter of Capacitors and Power Factor Correction Capacitors providing the best quality products and services to our customers.
These capacitors are especially designed for the Fan industry, i.e. Ceiling Fans, Table Fans, Pedestal Fans, Industrial Fans etc. The ergonomic design and high efficiency makes these capacitors complete value for money. MPP Capacitors for Fan are available in different sizes and shape. You can choose one as per your requirements and budget.
- Low dissipation factor.
- Small inherent temperature rise.
- Excellent self-healing stability.
- Noise Reduction.
- Motor Protection
- Compact Design, Cost Efficiency.
| Capacitance Range | : | 0.5 to 4 MFD |
| Capacitance Tolerance | : | ±5% |
| Rated Voltage | : | 220V AC to 450V AC |
| Rated Frequency | : | 50/60Hz |
| Tan Delta | : | ≤0.0020(100Hz) |
| Climatic Category | : | -25/85/21, -40/85/21 |
| Case | : | Plastic & Aluminium (as per customers specs) |
| Dielectric | : | Polypropylene |
| Encapsulation | : | Polyurethane Resin (PP-Dry & Oil Filled) |
| Reference Standards | : | IEC 60252 , IS:2993 & IS:1709 |
